Hytera HP685 Professional DMR Portable Two-way Radio

Name: Hytera HP685 Professional DMR Portable Two-way Radio
Brand: Hytera
Availability: InStock

Small and light in style, the HP685 handheld DMR radio delivers class-leading audio performance and extended coverage together with a Lithium Polymer battery, ability to operate in extreme environments and support for abundant features. The Hytera HP685 DMR handheld is an easy-to-use two way digital radio tool for customer-facing staff, enabling them to focus on their daily tasks and improve efficiency.

Highlights of HP685

LIGHT AND STYLISH

The streamlined Hytera HP685 is compact and light and designed for ease of use with a Tactile PTT and programmable buttons for common functions. The integrated BT5.0 technology provides flexible wireless connection with accessories for hands-free operation.

CLEAR AUDIO

The Hytera HP685 uses the cutting-edge AI-based noise cancellation technology to decrease the unwanted background noise and reduce howling, maintaining high audio clarity. Users can now hear and be heard regardless of any noise.

LONG BATTERY LIFE

The Hytera HP605 has a long battery life over 20 hours @ 5-5-90 as standard. Users no longer need to charge the radio or change the battery during their shift

RUGGED AND DURABLE

Manufactured to meet MIL-STD-810 G standard, the HP685 is IP67 rated and can withstand a 2-meter drop to stand up to a the toughest user environments

EASY TO USE

The HP6 series is designed for ease of use in a compact and discreet form. Tactile PTT, programmable buttons and keys allow professionals to respond positively.

EXTENDED RANGE

Thanks to the improved receiver sensitivity, the HP6 series provides better connectivity both in marginal areas of coverage and indoors. This will deliver improved safety and operational benefits for operatives in the field.

ROAMING

Optional, roaming allows radios to move between sites in the IP Multi-site Connect system or XPT Multi-site system without dropping connection.

Specifications of Hytera HP685

General data
Frequency Range	VHF: 136-174 MHz UHF: 400-527 MHz
Channel Capacity	1024
Zone Capacity	64 (256 channels per zone)
Channel Spacing	12.5 kHz/20 kHz/25 kHz
Operating Voltage	7.7 V(rated)
Battery	2000 mAh Li-polymer
Battey Life(5/5/90 Duty Cycle,High TX Power)	GNSS disabled: 20 hours; GNSS enabled: 16hours
Frequency Stability	±0.5 ppm
Antenna Impedance	50 Ω
Dimensions(H×W×D) mm	122 mm ×55 mm ×31.5 mm
Weight	280 g
Display	1.8 inch, 4 rows, 160 x 128 pixels, 65536 colours
BT	V5.0 BLE+EDR (hardware option)

Environmental Specs
Operating Temperature	-30 ℃*～+60 ℃
Storage Temperature	-40 ℃～+85 ℃
ESD	IEC 61000-4-2 (Level 4); ±15 kV (air); ±8 kV (contact)
MIL Standard	MIL-STD-810 C/D/E/F/G
Dust & Water Protection	IP67
Humidity	MIL-STD-810 G
Vibration,Drop&Shock	MIL-STD-810 G
